SMA Plug 5dbi 5G 4G LTE Sub Antenna 617 - 5850MHz

Product Detail

5G Antenna 4G Lte Sub Antenna Sma Plug 617-5850mhz 5dbi For 5g Gateway



PRODUCT SPECIFICATIONS



Electrical

Frequency

617~960MHz/1452~1620MHz/1710~2690MHz/3300~5850MHz

Gain

5 dBi (maximum)

VSWR

< 3.5 typ.

Efficiency

(The test results are based on single antenna)

70 %

Polarization

Vertical

Impedance

50 ohms

Radiation

Omni-directional



Physical and Environmental

Dimension (DxL)

20.1 x 135.6 mm

Weight

14.7 g

Connector

SMA PLUG or customized

Material

ABS

Operating Temperature

-20℃ ~ +65℃



There is no dead angle while transmission and reception implemented of this antenna, can stably receive signals from all directions.
Low Gain Loss PCB material to be durable and stable
Thermoplastic Material: anti corrision, anti salt spray, heat resistant, stable material

FAQ :



Q: What's your company MOQ?
A: In generally, we will ask at least 100~1000pcs, this we can negotiate.

Q: What's your delivery time?
A: This please check our stock in first, products can be sendtout once receive your payment. Usually, 7-14 days for mass production.

Q: Can your company accept customize?
A: Welcome OEM & ODM.

Q: How do you solve after sale service?
A: One year guarantee. Replacement of defective ones after negotiation.

Q: Can you send a sample for us to develop?
A: Yes, we can. Sample can be sent out once you ask for it, but will ask a sample fee.
