RHCP Polarization SMA GPS Antenna With RG174 Cable

Product Detail

SMA Antenna GPS Antenna SMA With RG174 Cable Length 3m



Electrical Specifications



Frequency Range (MHz):1567.75±9
Gain (dBi):>3
Axial ratio (dB):<7
VSWR:<2
Polarization:RHCP



LNA Electrical Specifications



Frequency Range ( MHz):1567.75±9
Gain ( dB):(28±2)@3.3V
VSWR:≤2.0@3.3V
Noise Factor (dB):≤1.5dB@3.3V
Out of band attenuation(dB):>30@fo ± 100MHz
In-band flatness (dB):<1
Power ( V):DC (2.8~5)V
Supply Electricity (mA):<20@3.3V



Other Parameter



Output impedance:50Ω
Radome material:ABS
Input Connector:FAKRA
Dimensions of Antenna ( mm):50*51*15.6
Working Temperature (℃):-40~+85
Storage temperature (℃):-40~+90
Cable length:3m
Weight (g):72±5g
Waterproof:IP66



the signal amplification, transmission to the host are analyzed, the positioning and navigation. Our GPS active antenna with good axial ratio, standing wave,
high gain, low loss characteristics.
We can definitely ensure the products out-standing, stable performance, qualified certificates. Equiped with professional R&D team, along with our culture of quality assurance, Competitive price, Good after-sales Service for you.

FAQ :



Q: What's your company MOQ?
A: In generally, we will ask at least 100~1000pcs, this we can negotiate.

Q: What's your delivery time?
A: This please check our stock in first, products can be sendtout once receive your payment. Usually, 7-14 days for mass production.

Q: Can your company accept customize?
A: Welcome OEM & ODM.

Q: How do you solve after sale service?
A: One year guarantee. Replacement of defective ones after negotiation.

Q: Can you send a sample for us to develop?
A: Yes, we can. Sample can be sent out once you ask for it, but will ask a sample fee.
