15dBi N Female Dual Polarization Electrically Tunable Antenna15dBi N Female Dual Polarization

Product Detail

Dual Polarization Electrically Tunable Antenna 820960 15 H65E14 0°-14° Wireless 10 50 N-Female Pole-Holding Vertical



Product Description



Frequency Range (MHz):820-960
Gain(dBi):15±1
Horizontal Beam Width(°):65±6
Vertical Beam Width(°): 14±2
Electrical Downtilt(°): 0~14
VSWR:≤1.5:1
Isolation between Ports(dB):≥28
Upper Sidelobe Suppression(dB): >16
Front to Back Ratio(dB):>25
Polarization:±45°
Input Maximum CW Power(W):200
PIMD 3th:≤-107dBm(@20W)
Impedance(Ω):50
Input Connector:7/16DIN Female
Dimensions of Antenna(mm):1700×1700×2300
Weight of Antenna(kg):90kg
Temperature(℃):-40~+60
Max Wind Speed (m)/s:55
Radome Material:Plastic or FRP


Easy to installation, increase signal strength
All parts are tested and quality controlled prior to shipment
Use Range: Wifi Module, AP, Wireless Router, Wireless Monitoring, Smart Home, Internet of Things Equipment, Communication Products, Dual-frequency Equipment, Etc.

FAQ :



Q: What's your company MOQ?
A: In generally, we will ask at least 100~1000pcs, this we can negotiate.

Q: What's your delivery time?
A: This please check our stock in first, products can be sendtout once receive your payment. Usually, 7-14 days for mass production.

Q: Can your company accept customize?
A: Welcome OEM & ODM.

Q: How do you solve after sale service?
A: One year guarantee. Replacement of defective ones after negotiation.

Q: Can you send a sample for us to develop?
A: Yes, we can. Sample can be sent out once you ask for it, but will ask a sample fee.
